◆Hexagon Socket Set Screws
●Materials：SNCM240
●Hardness：HmV500-560(HRC50〜53)
●Strength：Our hexagon socket have unbelievable toughness
againnst maximum wrenching forces.
Nominal
dia
Pitch
Hexagon
Flat point
Cup point
L
d
p
s
e
t1
t2
dpmin
dpmax
dzmin
dzmax
2.0
2.5
3.0
4.0
5.0
6.0
M1.6
0.35
0.71
0.803
0.7
1.5
0.55
0.8
0.55
0.8
●
●
●
●
M1.7
0.35
0.71
0.803
0.7
1.5
0.55
0.8
0.55
0.8
●
●
●
●
●
M2.0
0.4
0.89
1.003
0.8
1.7
0.75
1.0
0.75
1.0
●
●
●
●
●
●
Recommended Tightening Torque(N・m)
Size
Depth t1
Depth t2
M1.6
0.06
0.08
M1.7
0.06
0.08
M2.0
0.12
0.17
※1.
Hexagon depth 1 apply to ●, depth t 2apply to ●.
※2.
Recommended tightening torque depend on Hexagon depth t.
※3.
Available Size Range Up To M5
OUR MICRO SCREWS ARE FINISHED THROUGH VACUUM FURNACE DRYER AFTER BLACK OXIDE TREATMENT, SO THE SCREWS ALWAYS CLEAN WHITOUT YOUR HANDS MAKE DIRTY WITH OILS.
THAT MEANS OUR SCREWS ARE BEST FIT FOR YOUR AUTOMATIC ASSEMBLING
Manufacturer
NAGAI PRECISION SCREWS MFG.CO.,LTD.
No.9-13,4-chome,Higashi-Ogu
Arakawa-ku, Tokyo 116-0012, Japan
FAX:81-3-3893-8464
